Keypad Module DS-KD-KP Video Intercom Keypad Hikvision
Quick Overview
The Hikvision DS-KD-KP is a video intercom keypad module and is part of the 2nd generation of video intercom systems. This allows users to call the resident they are trying to reach by entering their room number or for residents to open the door by entering the password.
This module is operated by 12 physical buttons, with dimensions of 98.5mm(L) × 100mm(W) × 34.2mm(H) making it a great size, its not too big so it stands out too much but its not too small so users struggle to use it.
With a a working temperature of -40°C to 60°C, back light compensation (BLC), IP65 weather-proof housing and IK7 vandal-proof housing, this is perfect for outdoor use.
It can be installed by flush mounting or surface mounting, and is powered by DS-KD8003-IME1, by 12V DC using a maximum of 2W.
Specification
- System parameters
- Operating systemEmbedded Linux operation system
- ROM/
- RAM/
- CPUEmbedded MCU Processor
- Display parameters
- Screen size/
- Operation method/
- TypeNot supported.
- Resolution/
- Video parameters
- Lens/
- Resolution/
- FOV/
- WDRNot supported.
- Supplement lightNot supported.
- Video compression standard/
- Audio parameters
- Audio compression standard/
- Audio input/
- Audio outputNot supported.
- Audio compression bitrate/
- Audio quality/
- Volume adjustment/
- Capacity
- User capacity/
- Face capacityNot supported.
- Card capacity/
- Linked network camera capacity/
- Network parameters
- Communication protocol/
- Wired network/
- Wi-Fi standardNot supported.
- Bluetooth version/
- 3G/4G standard/
- Device interfaces
- Alarm input/
- Network interface/
- TAMPERNot supported.
- Exit button/
- RS-4851
- USB/
- Wiegand/
- TF card/
- Alarm output/
- Lock control/
- Door contact input/
- Power interface1
- Performances
- Multi-factor authentication/
- General
- Button12
- InstallationFlush mounting, surface mounting
- Indicator/
- Weight
With package: 529 g
Without package: 265 g
- Protective levelIP65, IK7
- Working temperature-40° C to +55° C(-40° F to 131° F)
- Working humidity10% to 95%
- Dimensions98.5 mm × 100 mm × 34.2 mm (3.87" × 3.95" × 1.33")
- Battery/
- Application environmentOutdoor
- Power consumption1 W
