DS-KD8003-IME1/S IP Modular stainless steel video intercom module door station
DS-KD8003-IME1/S IP Modular stainless steel video intercom module door station
The Hikvision DS-KD8003-IME1/Surface is a 2MP fisheye video intercom module door station that comes with the surface mounting accessory DS-KD-ACW1 already attached. It also comes with wide dynamic range (WDR), IR supplement light and night visibility.
As part of Hikvision's 2nd generation, this video intercom comes with bigger name-tag customization, low illumination, noise suppression and echo cancellation.
Armed with 180° horizontal field of view, 96° vertical field of view, IP65 weather-proof housing, a working temperature of -40°C to 60°C allowing it to be perfect for outdoor use.
Powered by either 12V DC or standard PoE, making it quick and easy to install.
Key Features
- 2 MP HD video intercom function.
- Low illumination.
- Noise suppression and echo cancellation.
- Fisheye camera with IR supplement light.
- H.264 video compression.
- Tampering alarm supported.
- Access control function.
- Supports sub-modules access (max. 8).
- Easy to and extend
Specification
- Display parameters
- Size/
- Operation method/
- Type/
- Video parameters
- Supplement light
IR supplement
- LensLow Illumination 2 MP HD IR Camera
- FOVHorizontal: 180°, Vertical: 96°
- Pixel
Main stream : 1920 × 1080
Sub stream : 720 × 480
- Audio parameters
- Audio qualityNoise suppression and echo cancellation
- Capacity
- Linked indoor station500
- Sub door station capacity16
- Network parameters
- Communication protocol
TCP/IP, RTSP
- Wired networkSupport
- Wi-Fi/
- Bluetooth/
- Device interfaces
- Network interface1 10/100M self-adaptive Ethenet
- Exit button2
- Lock control2
- Door contact input2
- Power interface1
- General
- Button/
- InstallationFlush mounting, surface mounting
- Indicator/
- Weight
Without package: 415 g
With package: 625 g
- Protective levelIP65
- Working temperature
-40° C to +55° C(-40° F to 131° F)
- Working humidity
10% to 95%
- Dimensions98 mm × 99.8 mm × 43.9 mm (3.86" × 3.93" × 1.73")
- Battery/
- Power supply
IEEE802.3af, standard PoE
12 VDC, 1 A
- Application environmentOutdoor
- Power consumption4 W
- LanguageEnglish, French, Portuguese (Brazil), Spanish, Russian, German, Italian, polish, Arabic, Turkish, Vietnamese, Hungarian, Dutch, Romanian, Czech, Bulgarian, Ukrainian, Croatian, Serbian, Portuguese, Slovak
