DS-1600KI Network Keyboard
Regular price
£724.00
Sale price
£724.00
Regular price
Unit price
Information
HIKVision Network Keyboard, 10.1 TFT LCD touchscreen (Resolution 1024*600), 4-axis joystick, WiFI supported, controllable of 2000 devices DVR/NVR/Network Camera/Speed Dome/PTZ, Local live view at
1080P/720P/HD1/BCIF/CIF/QCIF resolution and up to 16-division window display, HDMI/DVI video interface, USB2.0 interface for video backup, 3 Year Warranty
- 10.1" capacitive touchscreen
- Detachable design of the touchscreen and joystick
- Wired and WiFi network connection
- POE power supply
- Capable of decoding 2-ch at 1080P decoding; up to 16-division window display
- Live view on touch panel
- DVI and HDMI output to monitor
- Controllable of 2000 devices
- Access to Hikvision products including DVR, DVS, NVR,network camera, speed dome, etc.
- Control of MVC and decoders for video decoding and output on video wall
- PTZ control, setting and calling preset, patrol and pattern
- Support upgrade and configuration files import/export by USB flash disk
- Support recording and picture capturing; saving files in USB flash disk or uploading to FTP server
- Two-level user authority and up to 16 user accounts are configurable: one admin and 15 operators
Specification
- Interface
- USB Interface2 × USB 2.0
- Serial InterfaceNetwork, RS-232, RS-422, RS-485
- Network Interface
10M/100M/1000M adaptive ethernet port;
WiFi: Supported
- General
- Working Temperature-10 to +55° C (14 to 131° F)
- Working Humidity10% to 90%
- Net Weight1.7 kg (3.75 lb)
- Dimensions (W × H × D)404 mm × 163 mm × 180 mm (15.91" × 6.42" × 7.09")
- Power Consumption≤15 W
- Power Supply12 VDC/PoE
- Display10.1" TFT LCD touchscreen, Resolution: 1280 × 800
- Joystick4-axis joystick
- Video
- Video Output Interface Type1 ×HDMI, 1 ×DVI
- Audio
- Audio Input Interfaces1-ch, 3.5 mm connector (2.0 Vp-p, >1 KΩ)
- Audio Output Interfaces1-ch, 3.5 mm connector (2.0 Vp-p, 600 Ω)
- Video Decoding
- Video Decoding FormatH.264, H.264+, H.265, H.265+, MPEG4
- Video Decoding Capability1 channel of 4K@30fps, or 4 channels of 1,080P@30fps
- Certification
- Obtained CertificationCE-EMC/CE-LVD/ROHS/CB/UL/FCC-SDoC/RCM/BIS
