8MP DS-2CE76U1T-ITMF Hikvision Dome Grey
NEW HIKVISION OEM MODEL DS-2CE76U1T-ITMF 8MP 4K ULTRA HD RESOLUTION SURVEILLANCE CAMERA
Analog TurboHD TVI CVI 8MP 4K Resolution CCTV Bullet Camera, 2.8mm Lens, IR distance up to 30m, Indoor/Outdoor Use
This is a HD Analog camera that supports video output up to 8MP in HD-TVI and CVI, up to 5MP in HD-AHD, and CVBS 960H PAL/NTSC.
Product features:
8.29MP high-performance CMOS
3840 x 2160 resolution
2.8mm Fixed lens
Horizontal Field of view 102.2°
4 in 1 video output (switchable TVI/AHD/CVI/CVBS)
EXIR 2.0, smart IR up to 30m IR distance
Weatherproof IP67 rated
Up the Coax, Protocol: UTC-C (TVI Output)
Material: Metal
Power source: 12VDC *You are recommended to use one power supply adapter to supply the power for one camera
|
Image Sensor |
8.29 megapixel progressive scan CMOS |
|
Signal System |
PAL/NTSC |
|
Frame Rate |
TVI: 8MP@12.5fps, 8MP@15fps, 5MP@20fps, 4MP@25fps, 4MP@30fps, 2MP@25fps, 2MP@30fps |
|
Resolution |
3840 (H) × 2160 (V) |
|
Min. Illumination |
Color: 0.01 Lux@(F1.2, AGC ON), 0 Lux with IR |
|
Shutter Time |
PAL: 1/12.5 s to 1/50,000 s NTSC: 1/15 s to 1/50,000 s |
|
IR Range |
Up to 30 m |
|
Video Output |
1 HD analog output |
|
Synchronization |
Internal synchronization |
|
Lens |
2.8 mm fixed lens |
|
Horizontal Field of View |
102.2° (2.8 mm) |
|
Lens Mount |
M16 |
|
Day & Night |
IR cut filter |
|
Angle Adjustment |
Pan: 0° to 360°, Tilt:0° to 180°, Rotate: 0° to 360° |
|
White Balance |
Auto/Manual |
|
Image |
|
|
BLC |
Yes |
|
Menu |
|
|
AGC |
Yes |
|
DWDR |
105 dB |
|
Language |
English |
|
Functions |
Brightness, Sharpness, DNR, Mirror, Smart IR |
|
Interface |
|
|
Video Output |
1 HD analog output |
|
Switch Button |
TVI/AHD/CVI/CVBS |
|
Electrical |
|
|
Power Consumption |
Max. 5.3 W |
|
Construction |
|
|
Dimensions |
90 mm × 79.37mm (3.54" x 3.12") |
|
General |
|
|
Power Supply |
12 VDC ±25% |
|
Power Consumption |
Max. 5.3 W |
|
Dimensions |
90 mm × 79.37mm (3.54" x 3.12") |
|
Weight |
Approx. 345 g (0.76 lb.) |
|
Material |
Metal |
|
Operating Conditions |
40 °C to 60 °C (40 °F to 140 °F), humidity: 90% or less (noncondensation) |
|
Communication |
Up the coax, Protocol: UTCC (TVI output) |
|
Protection (General) |
IP67 |
This camera is a HIKVISION OEM product. Brown box without Hikvision logo and without product part number on the product.
NOTES:
This is a HD Analog Camera that need to work with 8MP HD Analog TVI/CVI DVRs. Kindly verify your DVRs specification to check compatibility. This is not a Network/IP/PoE camera and it's not compatible with NVRs/IP systems.
Specification
- Camera
- Image Sensor8.29 megapixel progressive scan CMOS
- Max. Resolution3840 (H) × 2160 (V)
- Min. IlluminationColor: 0.01 Lux @ (F2.0, AGC ON), 0 Lux with IR
- Shutter TimePAL: 1/12.5 s to 1/50,000 s;NTSC: 1/15 s to 1/50,000 s
- Day & NightIR Cut Filter
- Angle AdjustmentPan: 0° to 360°, Tilt:0° to 75°, Rotate: 0° to 360°
- Signal SystemPAL/NTSC
- Lens
- Lens Type2.8 mm, 3.6 mm, 6 mm fixed focal lens
- Focal Length & FOVHorizontal FOV: 102.2° (2.8 mm), 79° (3.6 mm), 50.8° (6 mm)
- Lens MountM16
- Illuminator
- Supplement Light TypeIR
- Supplement Light RangeUp to 30 m
- Smart Supplement LightYes
- Image
- Image SettingsBrightness;Sharpness;AGC
- Frame Rate
TVI: 8MP@12.5fps, 8MP@15fps, 4MP@25fps, 4MP@30fps, 2MP@25fps, 2MP@30fps
CVI: 8MP@12.5fps, 8MP@15fps
AHD: 8M@12.5fps, 8M@15fps
CVBS: 960H P/N
- Day/Night ModeAuto/Color/BW (Black and White)
- Wide Dynamic Range (WDR)Digital WDR
- Image EnhancementBLC;HLC
- Noise Reduction2D DNR
- White BalanceAuto/Manual
- Interface
- Video Output1 HD analog output;Switchable TVI/AHD/CVI/CVBS
- General
- Power
12 VDC ±25%, max. 5.3 W
*You are recommended to use one power adapter to supply the power for one camera.
- MaterialMetal
- Dimension90 mm × 79.37 mm (3.54" × 3.12" )
- WeightApprox. 310 g (0.68 lb.)
- Operating Condition
-40 °C to 60 °C (-40 °F to 140 °F)
Humidity: 90% or less (non-condensation)
- CommunicationHIKVISION-C
- LanguageEnglish
- Approval
- ProtectionIP67
