5MP Hikvision DS-2CE76H0T-ITMF(2.8mm)(C) Value Series, HDoC Turret Camera, IR 30M(2.8mm) (Offer)
5MP Hikvision DS-2CE76H0T-ITMF(2.8mm)(C) Value Series, HDoC Turret Camera, IR 30M(2.8mm) (Offer)
5MP Hikvision DS-2CE76H0T-ITMF(2.8mm)(C) Value Series, HDoC Turret Camera, IR 30M(2.8mm) (Offer)
The Hikvision DS-2CE76H0T-ITMF 5 MP Turret Camera provides high-definition analog output with a resolution of up to 2560 x 1944 pixels. TurboHD means that the analog signal can be sent over existing coaxial cable, eliminating the need to run new cables for high-definition video.
EXIR 2.0 is Hikvision’s proprietary IR extended range technology, which has a range of 98 feet (30 meters).
DWDR (Digital Wide Dynamic Range) ensures that ideal images are captured regardless of the lighting conditions. The camera also supports TVI, AHD, CVI, and CVBS video signals, and is water and dust resistant (IP67 rated).
Features
- 5MP turret camera.
- EXIR 2.0: advanced infrared technology with 30 m IR distance.
- Water and dust resistant (IP67).
Specification
- Camera
- Image Sensor5 MP CMOS image sensor
- Max. Resolution2560 (H) × 1944 (V)
- Min. IlluminationColor: 0.01 Lux @ (F2.0, AGC ON), 0 Lux with IR
- Shutter Time
PAL: 1/25 s to 1/50, 000 s
NTSC: 1/30 s to 1/50, 000 s
- Day & NightICR
- Angle AdjustmentPan: 0 to 360°, Tilt: 0 to 75°, Rotation 0 to 360°
- Signal SystemPAL/NTSC
- Lens
- Lens Type2.4 mm, 2.8 mm, 3.6 mm, 6 mm fixed lens
- Focal Length & FOV
2.4 mm, horizontal FOV: 103°, vertical FOV: 81°, diagonal FOV: 142°
2.8 mm, horizontal FOV: 86°, vertical FOV: 63°, diagonal FOV: 120°
3.6 mm, horizontal FOV: 80°, vertical FOV: 63°, diagonal FOV: 112°
6 mm, horizontal FOV: 55°, vertical FOV: 40°, diagonal FOV: 70°
- Lens MountM12
- Image
- Image Parameters SwitchSTD/HIGH-SAT
- Image SettingsBrightness, Sharpness, Mirror, Smart IR
- Frame Rate
TVI: 5M@20fps, 4M@30fps, 4M@25fps, 1080p@30fps, 1080p@25fps
AHD: 5M@20fps, 4M@30fps, 4M@25fps
CVI: 4M@30fps, 4M@25fps
CVBS: PAL/NTSC
- Day/Night ModeAuto/Color/BW (Black and White)
- Wide Dynamic Range (WDR)Digital WDR
- Image EnhancementBLC, HLC
- White BalanceATW/MANUAL
- AGCSupport
- Interface
- Video OutputSwitchable TVI/AHD/CVI/CVBS
- General
- Material Metal
- DimensionΦ 82.6 mm × 90 mm × 79.37 mm (Φ 3.25" × 3.54" × 3.12")
- WeightApprox. 289 g (0.64 lb.)
- Operating Condition-40 °C to 60 °C (-40 °F to 140 °F), humidity: 90% or less (non-condensation)
- CommunicationHIKVISION-C
- LanguageEnglish
- Power Supply12 VDC ±25%
- Consumption
Max. 4.3 W
- IR RangeUp to 30 m
- Approval
- ProtectionIP67
