16 Port DS-3E0518P-E Unmanaged Gigabit PoE+ Switch w/ 1 x GbE RJ45 & 1 x GbE SFP Port (230W) (Offer)
16 Port DS-3E0518P-E Unmanaged Gigabit PoE+ Switch w/ 1 x GbE RJ45 & 1 x GbE SFP Port (230W) (Offer)
Regular price
£207.99
Sale price
£207.99
Regular price
Unit price
Information
16-Port DS-3E0518P-E Unmanaged Gigabit PoE+ Switch w/ 1 x GbE RJ45 & 1 x GbE SFP Port (230W) (Offer)
The Hikvision DS-3E0518P-E 16-Port Unmanaged Rackmount Gigabit PoE+ Switch is a layer 2 Gigabit switch that provides sixteen (16) Gigabit PoE ports, one (1) 10/100/1000 Mbps RJ45 port, and one (1) 10/100/1000 Mbps SFP fibre optical port. This switch has advanced PoE technology and can connect to other devices with high performance. With the DS-3E0518P-E, all Gigabit ports guarantee stable transmission of data.
Key Features
- Sixteen (16) Gigabit PoE ports.
- One (1) Gigabit RJ45 port.
- One (1) Gigabit SFP fibre optical port.
- Supports IEEE 802.3at/af standard.
- IEEE 802.3, IEEE 802.3u, IEEE 802.3x, IEEE 802.3ab, and IEEE 802.3z standard.
- 6 KV surge protection for PoE ports.
- PoE power management.
- Gigabit network access.
- Wire-speed forwarding and non-blocking design.
- Store-and-forward switching.
- Solid high-strength metal shell.
Specification
- General
- ShellMetal material
- Net Weight2.67 kg (5.89 lb)
- Gross Weight3.53 kg (7.78 lb)
- Dimensions (W × H × D)440.0 mm × 44.0 mm × 220.8 mm (17.3'' × 1.7'' × 8.7'')
- Operating Temperature–10 °C to 55 °C (14 °F to 131 °F)
- Storage Temperature–40 °C to 85 °C (–40 °F to 185 °F)
- Operating Humidity5% to 95% (no condensation)
- Relative Humidity5% to 95% (no condensation)
- Power Supply100~240 VAC, 50/60 Hz, Max. 4 A
- Max. Power Consumption250 W
- Power Consumption in Idle20 W
- Installation ModeDesk-Mounted,Rack (equipped with mounting ears)
- Surge Protection6 KV
- Network Parameters
- Ports16 × Gigabit PoE port,1 × Gigabit RJ45 port,1 × Gigabit fiber optical port
- MAC Address Table8 K
- Switching Capacity36 Gbps
- Packet Forwarding Rate26.784 Mpps
- Internal Cache4.1 Mbits
- PoE Power Supply
- PoE StandardIEEE 802.3af,IEEE 802.3at
- PoE Power PinEnd-span: 1/2(+), 3/6(-)
- PoE PortPoE: Ports 1 to 16
- Max. Port Power30 W
- PoE Power Budget230 W
- Approval
- EMCFCC (47 CFR Part 15, Subpart B),CE-EMC (EN 55032: 2015+A11: 2020, EN IEC 61000-3-2: 2019, EN 61000-3-3: 2013+A1: 2019, EN 50130-4: 2011+A1: 2014, EN 55035: 2017+A11: 2020),IC (ICES-003: Issue 7:2020),RCM (AS/NZS CISPR 32: 2015)
- SafetyUL (UL 60950-1),CB (AMD1:2009, AMD2:2013, IEC 62368-1: 2014 (Second Edition), CE-LVD (EN 62368-1: 2014+A11: 2017)
- ChemistryCE-RoHS (2011/65/EU)
